Specifications
Drive System
Motor: 12” BOSCH 1500W Nominal, 3500W peak power, 150Nm peak torque.
Motor Controller: External FOC with dynamic vector control algorithm for speed/torque ratio BMOS connected and controlled electronic components.
Max speed: 70km/h
Max torque: 150 Nm at 450rpm
Colors
Black.
Green.
Blue.
Sand.
Power System
Standard Battery Pack
60V 30AH Panasonic Lithium-Ion battery pack.
Optional Battery Pack
Additional 60V 30AH Panasonic battery pack for double range.
Power System Protection
85A resettable circuit breaker, low-voltage cut-out (by controller), Battery protected by BMS.
Standard Charger
Li-Ion outboard, 60V 5A Automatic Charger, 120VAC input ~6.5-hour charge time.
12V System Converter
DC/DC 60V<12V 10A (powers all lighting and accessory outlet)
User-removable Battery
Yes.
12V Outlet
No.
USB Charging Port
No.
Bluetooth Sound System
Optional.
Hydraulic Disk Brakes
Right Lever – activates Racer type 180 mm rear linked with 1sec delay to the 220mm front disk hydraulic brakes for avoiding jackknifing.
Left Lever – activates 180mm rear disk only.
Running Gear
Electric Brakes
Regenerative, acting on rear wheel (via hub motor), triggered by front or rear brake actuation.
Suspension
Front: Inverted 700mmX35mm twin internal hydraulic shocks with 200mm travel distance.
Rear: Adjustable trailing arm over spring/hydraulic shock.
Tires & Wheels
Front:
Tire: 90/80 -17” tubeless motorcycle grade DOT-spec.
Wheel: MT 1.5X17cast Aluminum alloy.
Rear:
Tire: 110/70-17” tubeless motorcycle grade DOT-spec.
Wheel: MT 2.5×17” Aluminum alloy with integral 12” BOSH motor.
Body & Chassis
Frame
Racing type engineered, split concept Carbon steel/ 2024 Aluminum Alloy.
Shell
ABS composite, epoxy paint.
Foot Rest
6 positions for rider, adjustable in height for passenger.
Seat
Padded, double place, 76cm (30”) above ground.
Instruments
Classic/LCD bright dashboard displays Current speed, Total mileage, Error codes, Real time output current, Battery State of Charge, trip distance and remaining distance, Ambient temperature and current time.
Safety equipment
Automatic Light mode estimating the ambient light for the right intensity.
Dual rear-view mirrors, horn, dual high/low beam automotive grade LED headlights with running light, front and rear turn signals, tail light, brake light.
License plate light.
Hazard lights, LED headlight bulb with focusing optic.
Security
Keyless start, Built-in vibration sensitive alarm system with two remote controls, steering lock, Electronic lock of the rear wheel.
Performance
Top Speed: 70km/h as per LSM regulations.
Range:
|
Mode
|
Single Battery
|
Double Battery
|
|
Eco mode (45 km/h)
|
80 km
|
160 km
|
|
Normal (62 km/h)
|
60 km
|
120 km
|
|
Sport (70km/h)
|
50 km
|
100 km
|
Climbing ability:
|
LOAD
|
%
incline |
|
|
Kg
|
Lbs
|
|
|
60
|
132
|
26.8
|
|
75
|
165
|
23
|
|
90
|
198
|
19.4
|
|
105
|
231
|
17.2
|
|
120
|
264
|
16
|
Dimensions and Weights
Weight (without battery pack): 70.5kg (155lb).
Battery Pack Weight: 13.5kg (30lb).
Optional Battery Pack Weight: 13.5kg (30lb).
Wheelbase: 132cm (52”).
Seat height: 74cm (29”).
Overall length: 189cm (74”).
Maximum payload capacity, including rider(s): 115 kg (250 lb).
Optional Accessories
GPS tracker
Rear rack
Storage box
Helmet
Goggles
Windshield
Rain cover
